Yongnuo RF-603 II User Manual

The name of each parts of RF-603 II
The RF-603C II is
more suitable for
Canon cameras.
The RF-603N II is
more suitable for
Nikon cameras.
4
A: Focusing indicator light (green) /
Shutter indicator light (red)
B: 2.5mm shutter remote cable socket
C: Hot shoe / Hot shoe contacts
D: PC socket(output)
E: Awakening indicator light (green) /
Flash trigger indicator light (red)
F: Multifunction button
G: Power switch- 1.TX
2.TRX(transmit-receive )
H: Locking ring
I: Hot shoe mounting foot
J: Contacts
K: Channel setting switch
L: Battery room
M:Battery door
(transmit)

Yongnuo RF-603 II Specifications

General

Brand	Yongnuo
Model	RF-603 II
Category	Camera Accessories
Language	English
