Preparation before using
1.Channel Setting:
Use the channel setting switch to set the transceivers
to the same code, total 16 channels.
2.Battery Installation:
Slide to open the battery room, install two AAA
batteries(not include) for two transceiver according to
the "+/-" marks shown.
3.Fix the transceiver on the camera hot shoe:
Mount the transceiver on the hot shoe of the camera by
hot shoe mounting foot, then tight the locking screw.
Support installing the flash on the transceiver (The
On-Top Flash,as the picture shown).
5
