Preparation before using
4.Fix the transceiver on light stand or flash bracket :
Mount the transceiver on the mini stand of the flash
attached or other fixed device (not included), and tight the
locking screw.
5.Fix the flash on transceiver:
Install the flash on the hot shoe of the transceiver, lock the
flash and ensure all links are fixed well.
6.Use the PC port to connect other type of flashes :
To realize the function you need to additionally purchase
the LS-PC series cable according to the different interface.
1.Inset the PC cable with the end of nutsert to PC socket of
the transceiver, and tight the nutsert.
2.Inset another end of the cable to the synchronous socket
of the the flash.
The PC port just used as output to connect the flash.
6
