York AFFINITY BHP024 - Cooling Capacities - 4 Ton (BHP048)

036-21528-007-A-1205
10 Unitary Products Group
TABLE 7: COOLING CAPACITIES - 4 TON (BHP048)
TEMPERATURE AIR ON
OUTDOOR COIL
TEMPERATURE OF AIR ON INDOOR COIL
1500 CFM 1600 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 54.3 50.4 45.7 48.2 54.9 51.0 46.3 48.8
POWER INPUT kW 3.97 3.85 3.75 3.74 4.06 3.94 3.83 3.83
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 35.5 45.1 45.7 48.2 37.2 47.1 46.3 48.8
83 31.2 40.8 45.3 47.5 32.5 42.4
46.3 48.8
80 26.8 36.4 43.7 45.2 27.8 37.8 45.3 46.9
77 22.5 32.0 39.3 40.9 23.2 33.1 40.6 42.3
74 18.1 27.7 35.0 36.5 18.5 28.4 36.0 37.6
71 #N/A 23.3 30.6 32.2 #N/A 23.8 31.3 32.9
68 #N/A 19.0 26.3 27.8 #N/A 19.1 26.6 28.3
95 °F
NET CAP. MBH 52.0 47.4 43.5 46.1 52.3 47.7 43.8 46.4
POWER INPUT kW 4.33 4.25 4.17 4.11 4.43 4.35 4.26 4.20
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 34.6 43.5 43.5 46.1 36.1 45.3 43.8 46.4
83 30.3 39.1 43.1 45.4 31.5 40.6 43.8 46.4
80 25.9 34.8 42.1 43.2 26.8 36.0 43.6 44.7
77 21.5 30.4 37.8 38.8 22.1 31.3 38.9 40.0
74 17.2 26.1 33.4 34.5 17.5 26.6 34.3 35.3
71 #N/A 21.7 29.1 30.1 #N/A 22.0 29.6 30.7
68 #N/A 17.3 24.7 25.8 #N/A 17.3 24.9 26.0
105 °F
NET CAP. MBH 48.8 44.2 40.1 43.2 49.0 44.5 40.3 43.5
POWER INPUT kW 4.71 4.62 4.52 4.47 4.81 4.71 4.61 4.56
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 32.0 40.2 40.1 43.2 33.5 41.8 40.3 43.5
83 28.0 36.5 39.7 41.8 29.2 38.0 40.1 42.7
80 23.9 32.4 39.6 39.3 24.8 33.6 41.0 40.8
77 19.9 28.4 35.5 35.3 20.5 29.3 36.7 36.4
74 15.9 24.3 31.5 31.2 16.1 24.9 32.3 32.0
71 #N/A 20.3 27.4 27.2 #N/A 20.6 28.0 27.7
68 #N/A 16.2 23.4 23.1 #N/A 16.2 23.6 23.3
115 °F
NET CAP. MBH 45.9 41.4 37.0 40.7 46.1 41.5 37.1 40.8
POWER INPUT kW 5.19 5.08 4.96 4.93 5.28 5.17 5.05 5.02
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 31.0 38.7 37.0 40.7 32.5 40.2 37.1 40.8
83 26.9 35.3
37.0 39.3 28.1 36.8 37.1 40.1
80 22.9 31.3 38.4 36.9 23.8 32.5 39.9 38.3
77 18.8 27.2 34.4 32.9 19.4 28.1 35.6 34.0
74 14.8 23.2 30.4 28.8 15.0 23.8 31.2 29.6
71 #N/A 19.1 26.3 24.8 #N/A 19.4 26.8 25.3
68 #N/A 15.1 22.3 20.7 #N/A 15.0 22.5 20.9
125 °F
NET CAP. MBH 43.1 38.5 33.9 38.1 43.2 38.6 34.0 38.2
POWER INPUT kW 5.66 5.53 5.40 5.39 5.76 5.63 5.50 5.48
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 29.9 37.3 33.9 38.1 31.4 38.6 34.0 38.2
83 25.9 34.2 34.2 36.8 27.0 35.7 34.1 37.5
80 21.8 30.1 37.3 34.5 22.7 31.3 38.8 35.9
77 17.8 26.1 33.3 30.5 18.3 27.0 34.5 31.5
74 13.7 22.0 29.3 26.4 14.0 22.6 30.1 27.2
71 #N/A 18.0 25.2 22.4 #N/A 18.3 25.7 22.8
68 #N/A 14.0 21.2 18.4 #N/A 13.9 21.4 18.5
1.
These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
