York AFFINITY BHP024 - Cooling Capacities - 3 Ton (BHP036)

036-21528-007-A-1205
8 Unitary Products Group
TABLE 5: COOLING CAPACITIES - 3 TON (BHP036)
TEMPERATURE AIR ON
OUTDOOR COIL
TEMPERATURE OF AIR ON INDOOR COIL
1050 CFM 1200 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 41.1 37.5 34.5 34.3 42.4 38.6 35.5 35.3
POWER INPUT kW 2.89 2.81 2.73 2.73 3.00 2.91 2.83 2.82
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 25.6 32.3 34.5 34.3 28.2 35.5 35.5 35.3
83 22.5 29.3 33.5 33.6 24.7 32.0
35.5 35.3
80 19.5 26.3 31.7 32.2 21.2 28.5 34.5 35.0
77 16.5 23.2 28.7 29.1 17.7 25.0 31.0 31.5
74 13.4 20.2 25.7 26.1 14.2 21.6 27.5 28.0
71 #N/A 17.2 22.6 23.1 #N/A 18.1 24.0 24.5
68 #N/A 14.1 19.6 20.0 #N/A 14.6 20.5 21.0
95 °F
NET CAP. MBH 38.5 34.9 32.5 32.6 39.4 35.8 33.3 33.4
POWER INPUT kW 3.21 3.15 3.05 3.06 3.31 3.25 3.15 3.16
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 25.0 30.9 32.5 32.6 27.5 33.9 33.3 33.4
83 22.0 27.9 31.9 32.0 24.0 30.4 33.3 33.4
80 19.0 24.8 30.5 30.6 20.5 26.9 33.0 33.1
77 15.9 21.8 27.5 27.5 17.0 23.4 29.5 29.6
74 12.9 18.8 24.4 24.5 13.5 19.9 26.0 26.1
71 #N/A 15.7 21.4 21.5 #N/A 16.4 22.5 22.6
68 #N/A 12.7 18.4 18.5 #N/A 12.9 19.0 19.1
105 °F
NET CAP. MBH 35.6 32.1 29.5 30.4 36.4 32.8 30.2 31.1
POWER INPUT kW 3.61 3.52 3.44 3.45 3.70 3.61 3.53 3.54
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 23.9 29.4 29.5 30.4 26.2 31.9 30.2 31.1
83 20.9 26.6 29.2 30.0 22.7 28.9
30.2 31.1
80 17.9 23.6 27.8 28.6 19.2 25.4 30.0 30.8
77 14.8 20.5 24.8 25.5 15.7 21.9 26.5 27.3
74 11.8 17.5 21.8 22.5 12.2 18.4 23.0 23.8
71 #N/A 14.5 18.7 19.5 #N/A 14.9 19.5 20.3
68 #N/A 11.4 15.7 16.4 #N/A 11.4 16.0 16.8
115 °F
NET CAP. MBH 32.6 29.3 26.5 28.2 33.3 29.9 27.0 28.8
POWER INPUT kW 4.01 3.88 3.83 3.84 4.10 3.97 3.91 3.92
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 22.8 27.8 26.5 28.2 25.0 29.9 27.0 28.8
83 19.8 25.3 26.5 28.0 21.5 27.4
27.0 28.8
80 16.8 22.3 25.2 26.5 18.0 23.9 27.0 28.5
77 13.7 19.2 22.2 23.5 14.5 20.4 23.5 25.0
74 10.7 16.2 19.1 20.5 11.0 16.9 20.0 21.5
71 #N/A 13.2 16.1 17.4 #N/A 13.4 16.5 18.0
68 #N/A 10.1 13.1 14.4 #N/A 9.9 13.0 14.5
125 °F
NET CAP. MBH 29.7 26.4 23.5 26.0 30.2 26.9 23.9 26.4
POWER INPUT kW 4.41 4.25 4.21 4.22 4.49 4.33 4.29 4.30
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 21.7 26.3 23.5 26.0 23.7 27.9 23.9 26.4
83 18.7 24.0 23.8 25.9 20.2 25.9
23.9 26.4
80 15.7 21.0 22.6 24.5 16.7 22.4 24.1 26.2
77 12.6 17.9 19.5 21.5 13.2 18.9 20.6 22.7
74 9.6 14.9 16.5 18.4 9.7 15.4 17.1 19.2
71 #N/A 11.9 13.5 15.4 #N/A 11.9 13.6 15.7
#78 #N/A 8.8 10.4 12.4 #N/A 8.4 10.1 12.2
1.
These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
