York AFFINITY BHP024 - Cooling Capacities - 5 Ton (BHP060)

036-21528-007-A-1205
Unitary Products Group 11
TABLE 8: COOLING CAPACITIES - 5 TON (BHP060)
TEMPERATURE AIR ON
OUTDOOR COIL
TEMPERATURE OF AIR ON INDOOR COIL
1600 CFM 2000 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 64.0 58.5 53.4 53.1 64.5 59.0 53.8 53.6
POWER INPUT kW 4.62 4.55 4.46 4.31 5.08 5.00 4.90 4.74
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 39.3 48.7 53.4 53.1 44.8 55.1 53.8 53.6
83 34.6 44.1 52.7
53.1 38.8 49.2 53.8 53.6
80 30.0 39.4 48.0 52.3 32.9 43.2 52.6 53.6
77 25.3 34.8 43.3 47.6 26.9 37.2 46.6 47.6
74 20.7 30.1 38.7 42.9 20.9 31.3 40.7 41.6
71 -- 25.4 34.0 38.3 -- 25.3 34.7 35.7
68 -- 20.8 29.3 33.6 -- 19.3 28.8 29.7
95 °F
NET CAP. MBH 61.1 55.7 50.8 50.2 60.5 55.1 50.3 49.7
POWER INPUT kW 5.08 5.01 4.89 4.74 5.59 5.51 5.37 5.22
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 38.1 47.4 50.8 50.2 43.4 53.5 50.3 49.7
83 33.5 42.8 50.8 50.2 37.4 47.5 50.3 49.7
80 28.8 38.1 46.7 49.4 31.4 41.6
50.3 49.7
77 24.1 33.4 42.0 44.7 25.5 35.6 44.4 43.7
74 19.5 28.8 37.4 40.1 19.5 29.7 38.4 37.8
71 -- 24.1 32.7 35.4 -- 23.7 32.4 31.8
68 -- 19.4 28.0 30.7 -- 17.7 26.5 25.8
105 °F
NET CAP. MBH 56.9 51.2 46.8 47.2 56.3 50.7 46.3 46.7
POWER INPUT kW 5.64 5.52 5.37 5.28 6.17 6.04 5.88 5.77
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 36.7 45.7 46.8 47.2 41.9 49.9 46.3 46.7
83 32.0 41.1
46.8 47.2 35.9 45.9 46.3 46.7
80 27.3 36.4 46.7 46.1 30.0 39.9
46.3 46.7
77 22.7 31.7 42.0 41.5 24.0 34.0 40.3 40.7
74 18.0 27.1 37.3 36.8 18.0 28.0 34.4 34.8
71 -- 22.4 32.7 32.1 -- 22.0 28.4 28.8
68 -- 17.7 28.0 27.5 -- 16.1 22.4 22.8
115 °F
NET CAP. MBH 52.8 46.8 42.7 44.2 52.2 46.2 42.3 43.7
POWER INPUT kW 6.20 6.03 5.86 5.81 6.76 6.57 6.38 6.33
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 35.2 44.1 42.7 44.2 40.4 46.2 42.3 43.7
83 30.5 39.4
42.7 44.2 34.5 44.2 42.3 43.7
80 25.9 34.7 46.6 42.8 28.5 38.3
42.3 43.7
77 21.2 30.1 42.0 38.2 22.5 32.3 36.3 37.7
74 16.5 25.4 37.3 33.5 16.6 26.3 30.3 31.8
71 -- 20.7 32.6 28.8 -- 20.4 24.4 25.8
68 -- 16.1 28.0 24.2 -- 14.4 18.4 19.8
125 °F
NET CAP. MBH 48.7 42.3 38.7 41.2 48.0 41.8 38.2 40.7
POWER INPUT kW 6.77 6.54 6.34 6.34 7.34 7.10 6.89 6.88
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 33.7 42.4 38.7 41.2 39.0 42.6 38.2 40.7
83 29.1 37.7
38.7 41.2 33.0 42.5 38.2 40.7
80 24.4 33.0 46.6 39.5 27.0 36.6
38.2 40.7
77 19.7 28.4 41.9 34.9 21.1 30.6 32.3 34.7
74 15.1 23.7 37.3 30.2 15.1 24.7 26.3 28.7
71 -- 19.0 32.6 25.5 -- 18.7 20.3 22.8
68 -- 14.4 27.9 20.9 -- 12.7 14.4 16.8
1.
These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
