York AFFINITY BHP024 - Cooling Capacities - 3-1;2 Ton (BHP042)

036-21528-007-A-1205
Unitary Products Group 9
TABLE 6: COOLING CAPACITIES - 3-1/2 TON (BHP042)
TEMPERATURE AIR ON
OUTDOOR COIL
TEMPERATURE OF AIR ON INDOOR COIL
1300 CFM 1400 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 48.8 44.5 40.5 40.6 49.2 44.9 40.8 41.0
POWER INPUT kW 3.37 3.32 3.21 3.20 3.43 3.38 3.27 3.26
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 31.6 39.4 40.5 40.6 33.0 41.0 40.8 41.0
83 27.8 35.6 40.1 40.5 28.9 36.9
40.8 41.0
80 24.0 31.8 38.8 40.2 24.8 32.8 40.1 41.5
77 20.2 27.9 35.0 36.4 20.7 28.8 36.0 37.4
74 16.4 24.1 31.2 32.6 16.7 24.7 31.9 33.4
71 #N/A 20.3 27.4 28.7 #N/A 20.6 27.9 29.3
68 #N/A 16.5 23.5 24.9 #N/A 16.5 23.8 25.2
95 °F
NET CAP. MBH 45.4 41.5 38.3 38.5 45.7 41.9 38.6 38.8
POWER INPUT kW 3.67 3.66 3.54 3.54 3.72 3.71 3.60 3.60
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 30.7 38.2 38.3 38.5 32.0 39.8 38.6 38.8
83 26.9 34.4 38.1 38.3 27.9 35.7 38.6 38.8
80 23.0 30.6 37.5 37.9 23.9 31.6 38.8 39.2
77 19.2 26.8 33.6 34.0 19.8 27.6 34.7 35.1
74 15.4 23.0 29.8 30.2 15.7 23.5 30.6 31.0
71 #N/A 19.1 26.0 26.4 #N/A 19.4 26.5 26.9
68 #N/A 15.3 22.2 22.6 #N/A 15.3 22.4 22.8
105 °F
NET CAP. MBH 41.9 37.7 35.2 35.6 42.1 37.9 35.4 35.7
POWER INPUT kW 4.01 3.98 3.89 3.88 4.06 4.03 3.94 3.93
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 28.1 34.5 35.2 35.6 29.4 35.8 35.4 35.7
83 24.5 31.6 34.8 35.1 25.6 33.0 35.2 35.5
80 21.0 28.1 33.7 33.8 21.8 29.1 34.9 35.1
77 17.4 24.6 30.1 30.3 18.0 25.3 31.1 31.2
74 13.9 21.0 26.6 26.7 14.1 21.5 27.3 27.4
71 #N/A 17.5 23.0 23.2 #N/A 17.7 23.5 23.6
68 #N/A 13.9 19.5 19.6 #N/A 13.9 19.7 19.8
115 °F
NET CAP. MBH 38.7 34.2 32.4 32.9 38.8 34.3 32.5 33.0
POWER INPUT kW 4.41 4.35 4.28 4.28 4.46 4.40 4.33 4.32
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 26.8 32.5 32.4 32.9 28.1 33.4 32.5 33.0
83 23.3 30.2 32.1 32.3 24.3 31.5 32.3 32.7
80 19.7 26.7 31.2 31.0 20.5 27.7 32.4 32.2
77 16.2 23.1 27.6 27.5 16.7 23.9 28.6 28.4
74 12.6 19.6 24.1 24.0 12.9 20.1 24.8 24.6
71 #N/A 16.1 20.6 20.4 #N/A 16.3 20.9 20.8
68 #N/A 12.5 17.0 16.9 #N/A 12.5 17.1 17.0
125 °F
NET CAP. MBH 35.6 30.7 29.6 30.3 35.5 30.6 29.6 30.2
POWER INPUT kW 4.81 4.73 4.68 4.67 4.85 4.77 4.72 4.71
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 25.5 30.4 29.6 30.3 26.8 31.0 29.6 30.2
83 22.0 28.8 29.4 29.6 23.0 30.1 29.5 29.9
80 18.5 25.3 28.7 28.3 19.2 26.3 29.8 29.4
77 14.9 21.7 25.1 24.8 15.4 22.5 26.0 25.6
74 11.4 18.2 21.6 21.2 11.6 18.6 22.2 21.8
71 #N/A 14.6 18.1 17.7 #N/A 14.8 18.4 18.0
68 #N/A 11.1 14.5 14.1 #N/A 11.0 14.6 14.2
1.
These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
