TABLE 4: COOLING CAPACITIES - 2-1/2 TON (BHP030)
TEMPERATURE AIR ON
OUTDOOR COIL
TEMPERATURE OF AIR ON INDOOR COIL
1000 CFM 1125 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 34.1 31.5 28.4 29.9 35.4 32.7 29.5 31.0
POWER INPUT kW 2.52 2.48 2.44 2.43 2.64 2.58 2.54 2.53
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 23.9 29.8 28.4 29.9 25.7 31.8 29.5 31.0
83 21.0 26.9
28.4 29.9 22.4 28.5 29.5 31.0
80 18.1 23.9 27.9 29.6 19.0 25.2 29.2 30.8
77 15.2 21.0 24.9 26.6 15.7 21.9 25.9 27.5
74 12.3 18.1 22.0 23.7 12.4 18.5 22.6 24.2
71 #N/A 15.2 19.1 20.8 #N/A 15.2 19.2 20.9
68 #N/A 12.3 16.2 17.9 #N/A 11.9 15.9 17.5
95 °F
NET CAP. MBH 32.6 29.4 26.8 28.9 33.7 30.4 27.7 29.8
POWER INPUT kW 2.83 2.81 2.71 2.70 2.93 2.91 2.81 2.79
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 22.8 28.2 26.8 28.9 25.0 29.7 27.7 29.8
83 19.9 25.3 26.8 28.9 21.7 27.5 27.7 29.8
80 17.0 22.4 26.6 28.3 18.3 24.2 27.5 29.5
77 14.1 19.5 23.6 25.4 15.0 20.8 24.2 26.2
74 11.1 16.5 20.7 22.5 11.7 17.5 20.9 22.9
71 #N/A 13.6 17.8 19.6 #N/A 14.2 17.6 19.6
68 #N/A 10.7 14.9 16.7 #N/A 10.9 14.3 16.2
105 °F
NET CAP. MBH 30.3 27.2 25.0 26.7 31.5 28.2 26.0 27.7
POWER INPUT kW 3.14 3.12 3.04 3.06 3.24 3.22 3.14 3.16
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 21.7 26.6 25.0 26.7 23.9 27.9 26.0 27.7
83 18.8 24.1
25.0 26.7 20.6 26.3 26.0 27.7
80 15.9 21.1 25.4 26.3 17.2 22.9 26.2 27.5
77 13.0 18.2 22.4 23.3 13.9 19.6 22.9 24.2
74 10.1 15.3 19.5 20.4 10.6 16.3 19.6 20.9
71 #N/A 12.4 16.6 17.5 #N/A 13.0 16.2 17.6
68 #N/A 9.5 13.7 14.6 #N/A 9.7 12.9 14.2
115 °F
NET CAP. MBH 28.0 24.9 23.2 24.4 29.3 26.1 24.4 25.6
POWER INPUT kW 3.45 3.43 3.37 3.42 3.56 3.54 3.48 3.53
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 20.7 24.9 23.2 24.4 22.8 26.1 24.4 25.6
83 17.7 22.8
23.2 24.4 19.5 25.0 24.4 25.6
80 14.8 19.9 24.2 24.2 16.2 21.7 24.8 25.5
77 11.9 17.0 21.3 21.3 12.8 18.4 21.5 22.2
74 9.0 14.1 18.3 18.4 9.5 15.1 18.2 18.9
71 #N/A 11.2 15.4 15.4 #N/A 11.8 14.9 15.5
68 #N/A 8.3 12.5 12.5 #N/A 8.4 11.6 12.2
125 °F
NET CAP. MBH 25.6 22.7 21.4 22.2 27.2 24.0 22.7 23.5
POWER INPUT kW 3.76 3.74 3.70 3.78 3.87 3.85 3.82 3.89
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 19.6 23.3 21.4 22.2 21.7 24.3 22.7 23.5
83 16.7 21.6
21.4 22.2 18.4 23.8 22.7 23.5
80 13.7 18.7 23.0 22.1 15.1 20.5
23.5 23.5
77 10.8 15.8 20.1 19.2 11.7 17.2 20.2 20.2
74 7.9 12.9 17.1 16.3 8.4 13.9 16.8 16.8
71 #N/A 10.0 14.2 13.4 #N/A 10.5 13.5 13.5
68 #N/A 7.1 11.3 10.4 #N/A 7.2 10.2 10.2
1.
These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
