York AFFINITY BHP024 - Cooling Capacities - 2 Ton (BHP024)

036-21528-007-A-1205
6 Unitary Products Group
TABLE 3: COOLING CAPACITIES - 2 TON (BHP024)
TEMPERATURE AIR ON
OUTDOOR COIL
TEMPERATURE OF AIR ON INDOOR COIL
800 CFM 900 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 29.1 26.0 23.8 23.4 29.7 26.6 24.3 23.9
POWER INPUT kW 1.93 1.91 1.88 1.87 1.95 1.93 1.91 1.90
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 19.2 23.1 23.8 23.4 20.9 25.1 24.3 23.9
83 16.9 20.8
23.8 23.4 18.3 22.5 24.3 23.9
80 14.5 18.5 21.9 22.7 15.6 19.8 23.4 23.6
77 12.2 16.1 19.5 20.3 12.9 17.2 20.7 20.9
74 9.9 13.8 17.2 18.0 10.3 14.5 18.0 18.2
71 #N/A 11.5 14.9 15.7 #N/A 11.9 15.4 15.6
68 #N/A 9.1 12.5 13.3 #N/A 9.2 12.7 12.9
95 °F
NET CAP. MBH 27.2 24.2 22.1 22.0 27.7 24.6 22.5 22.4
POWER INPUT kW 2.07 2.06 2.02 2.02 2.09 2.08 2.05 2.04
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 18.6 22.3 22.1 22.0 20.1 23.7 22.5 22.4
83 16.2 20.0 22.1 22.0 17.5 21.5 22.5 22.4
80 13.9 17.7 20.8 21.4 14.8 18.9 21.8 22.1
77 11.6 15.3 18.4 19.0 12.2 16.2 19.2 19.4
74 9.2 13.0 16.1 16.7 9.5 13.5 16.5 16.8
71 #N/A 10.7 13.8 14.4 #N/A 10.9 13.8 14.1
68 #N/A 8.3 11.4 12.0 #N/A 8.2 11.2 11.5
105 °F
NET CAP. MBH 23.8 22.4 20.5 20.6 24.2 22.8 20.8 20.9
POWER INPUT kW 2.20 2.21 2.17 2.16 2.24 2.24 2.20 2.19
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 19.5 21.5 20.5 20.6 20.4 22.3 20.8 20.9
83 17.2 19.2
20.5 20.6 18.5 20.7 20.8 20.9
80 14.9 16.9 19.7 20.0 15.9 18.1 20.4 20.6
77 12.6 14.6 17.4 17.7 13.3 15.4 17.8 18.0
74 10.2 12.2 15.1 15.3 10.6 12.7 15.1 15.3
71 #N/A 9.9 12.7 13.0 #N/A 10.1 12.4 12.6
68 #N/A 7.6 10.4 10.7 #N/A 7.4 9.8 10.0
115 °F
NET CAP. MBH 20.4 20.7 18.9 19.2 20.6 20.9 19.1 19.4
POWER INPUT kW 2.34 2.36 2.32 2.31 2.38 2.40 2.36 2.35
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 20.4 20.7 18.9 19.2 20.6 20.9 19.1 19.4
83 18.2 18.5
18.9 19.2 19.5 19.8 19.1 19.4
80 15.9 16.1 18.7 18.6 17.0 17.3 19.0 19.1
77 13.6 13.8 16.4 16.3 14.4 14.6 16.4 16.5
74 11.2 11.5 14.1 14.0 11.7 11.9 13.7 13.8
71 #N/A 9.1 11.7 11.6 #N/A 9.3 11.1 11.2
68 #N/A 6.8 9.4 9.3 #N/A 6.6 8.4 8.5
125 °F
NET CAP. MBH 17.0 18.9 17.3 17.8 17.0 19.0 17.5 17.9
POWER INPUT kW 2.47 2.51 2.46 2.45 2.52 2.56 2.51 2.50
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 21.3 19.9 17.3 17.8 20.8 19.5 17.5 17.9
83 19.2 17.7
17.3 17.8 20.6 18.9 17.5 17.9
80 16.9 15.4
17.7 17.3 18.1 16.5 17.6 17.7
77 14.6 13.0 15.4 15.0 15.4 13.8 15.0 15.0
74 12.2 10.7 13.1 12.6 12.8 11.1 12.3 12.3
71 #N/A 8.4 10.7 10.3 #N/A 8.5 9.7 9.7
68 #N/A 6.0 8.4 8.0 #N/A 5.8 7.0 7.0
1.
These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
