5126744-UIM-D-1015
Johnson Controls Unitary Products 11
A42 18 112 28 1.7 5.4
none -- 1 -- 29.5 45 -- -- -- -- -- --
6HK(0,1)6500506 4.4 1 19.1 29.5 45 23.9 25 -- -- -- --
6HK(0,1)6500806 7.1 1 30.9 29.5 45 38.6 40 -- -- -- --
6HK(0,1)6501006 8.8 1 38.3 29.5 45 47.8 50 -- -- -- --
6HK16501306 11.5 2 50.0 29.5 45 62.5 45 23.9 25 -- --
6HK16501506 13.2 2 57.4 29.5 45 47.8 50 23.9 25 -- --
6HK16501806 15.9 2 69.1 29.5 45 57.6 45 28.8 45 -- --
6HK16502006 17.6 2 76.5 29.5 45 47.8 50 47.8 50 -- --
6HK26501306 11.5 1 50.0 29.5 45 62.5 70 -- -- -- --
6HK26501506 13.2 1 57.4 29.5 45 71.7 80 -- -- -- --
6HK26501806 15.9 1 69.1 29.5 45 86.4 90 -- -- -- --
6HK26502006 17.6 1 76.5 29.5 45 95.7 100 -- -- -- --
B48 22 117 34 1.7 5.4
none -- -- -- 34.4 50 -- -- -- -- -- --
6HK(0,1)6500506 4.4 1 19.1 34.4 50 23.9 25 -- -- -- --
6HK(0,1)6500806 7.1 1 30.9 34.4 50 38.6 40 -- -- -- --
6HK(0,1)6501006 8.8 1 38.3 34.4 50 47.8 50 -- -- -- --
6HK16501306 11.5 2 50.0 34.4 50 62.5 45 23.9 25 -- --
6HK16501506 13.2 2 57.4 34.4 50 47.8 50 23.9 25 -- --
6HK16501806 15.9 2 69.1 34.4 50 57.6 45 28.8 45 -- --
6HK16502006 17.6 2 76.5 34.4 50 47.8 50 47.8 50 -- --
6HK26501306 11.5 1 50.0 34.4 50 62.5 70 -- -- -- --
6HK26501506 13.2 1 57.4 34.4 50 71.7 80 -- -- -- --
6HK26501806 15.9 1 69.1 34.4 50 86.4 90 -- -- -- --
6HK26502006 17.6 2 76.5 34.4 50 95.7 100 -- -- -- --
B60 24 144 38 1.7 7.0
none -- -- -- 39.2 60 -- -- -- -- -- --
6HK(0,1)6500506 4.4 1 19.1 39.2 60 23.9 25 -- -- -- --
6HK(0,1)6500806 7.1 1 30.9 39.2 60 38.6 40 -- -- -- --
6HK(0,1)6501006 8.8 1 38.3 39.2 60 47.8 50 -- -- -- --
6HK16501306 11.5 2 50.0 39.2 60 62.5 45 23.9 25 -- --
6HK16501506 13.2 2 57.4 39.2 60 47.8 50 23.9 25 -- --
6HK16501806 15.9 2 69.1 39.2 60 57.6 45 28.8 45 -- --
6HK16502006 17.6 2 76.5 39.2 60 47.8 50 47.8 50 -- --
6HK26501306 11.5 1 50.0 39.2 60 62.5 70 -- -- -- --
6HK26501506 13.2 1 57.4 39.2 60 71.7 80 -- -- -- --
6HK26501806 15.9 1 69.1 39.2 60 86.4 90 -- -- -- --
6HK26502006 17.6 1 76.5 39.2 60 95.7 100 -- -- -- --
6HK16502506 22.0 3 95.7 39.2 60 47.8 50 47.8 50 23.9 25
6HK26502506 22.0 1 95.7 39.2 60 119.6 125 -- -- -- --
1. MCA = Minimum Circuit Ampacity.
2. MOP = Maximum Over Current Protection device; must be HACR type circuit breaker or time delay fuse.
Table 7: Electrical Data for 230-1-60 Multi Source Power
Model
Compressor
OD Fan
Motor
Blower
Motor
Electric Heat Option
Multi Source
Heater Kit
Heater kW
Stages
Heater Amps
RLA LRA MCC FLA FLA 230 230 230 230 230 230 230 230 230 230
Multi Source: Compressor
Circuit and Heat Circuits
Multi Source:
Circuit #1 Compressor Circuit
Circuit #2 Heat
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
Circuit #2 Heat
Circuit #3 Heat Circuit #1 Circuit #2 Circuit #3 Circuit #4
