York PCE4 Series User Manual

5126744-UIM-D-1015
Johnson Controls Unitary Products 13
Table 8: Physical Data
NOMINAL TONNAGE
MODELS
A24 A30 A36 A42 B48 B60
2.0 2.5 3.0 3.5 4.0 5.0
AHRI Cooling Performance
Gross Capacity @ AHRI A point (MBH) 23.7 30.1 37.2 43.5 47.7 55.0
AHRI net capacity (MBH) 22.8 29.0 34.6 40.7 45.5 52.5
EER 11.0 11.0 11.0 11.0 11.0 11.0
SEER 14.0 14.0 14.0 14.0 14.0 14.0
Nominal CFM 800 1000 1200 1400 1600 2000
System power (KW) 2.1 2.6 3.2 3.8 4.2 4.8
Refrigerant type R410A R410A R410A R410A R410A R410A
Refrigerant charge (lb-oz) 5-4 9-2 8-3 9-4 14-4 14-2
Dimensions (inches)
Length 51-1/4 51-1/4 51-1/4 51-1/4 51-1/4 51-1/4
Width 35-3/4 35-3/4 35-3/4 35-3/4 45-3/4 45-3/4
Height 47 47 47 49 53 55
Operating WT. (lbs.) 343 389 395 466 483 500
Compressors
Type Recip Recip Recip Scroll Scroll Scroll
Outdoor Coil Data
Face area (Sq. Ft.) 15.3 15.3 15.3 17.3 24.1 26.3
Rows 1 2 2 2 2 2
Fins per inch 22 22 22 22 22 22
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Indoor Coil Data
Face area (Sq. Ft.) 3.4 3.4 3.4 3.4 4.4 4.4
Rows 2 3 3 3 3 3
Fins per inch 16 16 16 16 16 16
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV TXV TXV TXV
Outdoor Fan Data
Fan diameter (Inch) 24 24 24 24 26 26
Type Prop Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct Direct
No. speeds 1 1 1 1 1 1
Motor HP each 1/4 1/4 1/4 1/4 1/3 1/3
RPM 850 850 850 850 850 850
Nominal total CFM 2400 2400 2400 2400 3200 3200
Direct Drive Indoor Blower Data
Fan Size (Inch) 11 x 8 11 x 8 11 x 10 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor HP each 1/2 1/2 1/2 3/4 3/4 1
RPM 1200 Max 1200 Max 1200 Max 1200 Max 1200 Max 1200 Max
Frame size 48 48 48 48 48 48
Filters
Filter Size A A A A B B
Quantity size
Field-supplied external filters must be sized so as not to exceed 300 fpm air velocity through disposable fil-
ters. For internal filter use, a filter rack kit is available. Consult the instructions supplied with that kit for
replacement filter sizes. Filter sizes: A=20x20, B=20x30.
