York PCE4 Series User Manual

5126744-UIM-D-1015
10 Johnson Controls Unitary Products
B60 24 144 38 1.7 7.0
none -- -- -- 39.2 60 -- -- -- -- -- --
6HK(0,1)6500506 3.6 1 17.3 39.2 60 21.6 25 -- -- -- --
6HK(0,1)6500806 5.8 1 27.9 39.2 60 34.9 40 -- -- -- --
6HK(0,1)6501006 7.2 1 34.6 39.2 60 43.3 45 -- -- -- --
6HK16501306 9.4 2 45.2 39.2 60 56.5 40 21.6 20 -- --
6HK16501506 10.8 2 51.9 39.2 60 43.3 50 21.6 25 -- --
6HK16501806 13.0 2 62.5 39.2 60 52.1 40 26.0 40 -- --
6HK16502006 14.4 2 69.2 39.2 60 43.3 45 43.3 45 -- --
6HK26501306 9.4 1 45.2 39.2 60 56.5 60 -- -- -- --
6HK26501506 10.8 1 51.9 39.2 60 64.9 70 -- -- -- --
6HK26501806 13.0 1 62.5 39.2 60 78.1 80 -- -- -- --
6HK26502006 14.4 1 69.2 39.2 60 86.5 90 -- -- -- --
6HK16502506 18.0 3 86.5 39.2 60 43.3 45 43.3 45 21.6 25
6HK26502506 18.0 1 86.5 39.2 60 108.2 110 -- -- -- --
1. MCA = Minimum Circuit Ampacity.
2. MOP = Maximum Over Current Protection device; must be HACR type circuit breaker or time delay fuse.
Table 7: Electrical Data for 230-1-60 Multi Source Power
Model
Compressor
OD Fan
Motor
Blower
Motor
Electric Heat Option
Multi Source
Heater Kit
Heater kW
Stages
Heater Amps
RLA LRA MCC FLA FLA 230 230 230 230 230 230 230 230 230 230
Multi Source: Compressor
Circuit and Heat Circuits
Multi Source:
Circuit #1 Compressor Circuit
Circuit #2 Heat
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
Circuit #2 Heat
Circuit #3 Heat Circuit #1 Circuit #2 Circuit #3 Circuit #4
A24 9 45 14 1.3 3.8
none -- -- -- 16.0 20 -- -- -- -- -- --
6HK(0,1)6500206 2.2 1 9.6 16.0 20 12.0 15 -- -- -- --
6HK(0,1)6500506 4.4 1 19.1 16.0 20 23.9 25 -- -- -- --
6HK(0,1)6500806 7.1 1 30.9 16.0 20 38.6 40 -- -- -- --
6HK(0,1)6501006 8.8 1 38.3 16.0 20 47.8 50 -- -- -- --
6HK16501306 11.5 2 50.0 16.0 20 41.7 45 20.8 25 -- --
6HK26501306 11.5 1 50.0 16.0 20 62.5 70 -- -- -- --
A30 10 57 15 1.3 3.8
none -- -- -- 17.4 25 -- -- -- -- -- --
6HK(0,1)6500206 2.2 1 9.6 17.4 25 12.0 15 -- -- -- --
6HK(0,1)6500506 4.4 1 19.1 17.4 25 23.9 25 -- -- -- --
6HK(0,1)6500806 7.1 1 30.9 17.4 25 38.6 40 -- -- -- --
6HK(0,1)6501006 8.8 1 38.3 17.4 25 47.8 50 -- -- -- --
6HK16501306 11.5 2 50.0 17.4 25 41.7 45 20.8 25 -- --
6HK16501506 13.2 2 57.4 17.4 25 47.8 50 23.9 25 -- --
6HK26501306 11.5 1 50.0 17.4 25 62.5 70 -- -- -- --
6HK26501506 13.2 1 57.4 17.4 25 71.7 80 -- -- -- --
A36 13 78 23 1.3 3.8
none -- -- -- 21.4 30 -- -- -- -- -- --
6HK(0,1)6500206 2.2 1 9.6 21.4 30 12.0 15 -- -- -- --
6HK(0,1)6500506 4.4 1 19.1 21.4 30 23.9 25 -- -- -- --
6HK(0,1)6500806 7.1 1 30.9 21.4 30 38.6 40 -- -- -- --
6HK(0,1)6501006 8.8 1 38.3 21.4 30 47.8 50 -- -- -- --
6HK16501306 11.5 2 50.0 21.4 30 41.7 45 20.8 25 -- --
6HK16501506 13.2 2 57.4 21.4 30 47.8 50 23.9 25 -- --
6HK26501306 11.5 1 50.0 21.4 30 62.5 70 -- -- -- --
6HK26501506 13.2 2 57.4 21.4 30 71.7 80 -- -- -- --
For notes, see Page 11.
Table 6: Electrical Data for 208-1-60 Multi Source Power (Continued)
Model
Compressor
OD Fan
Motor
Blower
Motor
Electric Heat Option
Multi Source
Heater Kit
Heater kW
Stages
Heater Amps
RLA LRA MCC FLA FLA 208 208 208 208 208 208 208 208 208 208
Multi Source: Compressor
Circuit and Heat Circuits
Multi Source:
Circuit #1 Compressor Circuit
Circuit #2 Heat
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
Circuit #2 Heat
Circuit #3 Heat Circuit #1 Circuit #2 Circuit #3 Circuit #4
