York PCE4 Series User Manual

5126744-UIM-D-1015
8 Johnson Controls Unitary Products
Table 5: Electrical Data - 208/230-1-60 - Single Source Power
Single Point Connection Kit Required
Model
Compressor
OD Fan
Motor
Blower
Motor
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max Fuse
2
or
Breaker
3
Size
2. Maximum Over Current Protection per standard UL 1995.
3. Fuse or HACR circuit breaker size installed at factory or field installed.
Heater Kit
Heater kW
Stages
Heater Amps
RLA LRA MCC FLA FLA 208 230 208 230 208 230 208 230
PCE4A24 9 45 14 1.3 3.8
none -- -- -- -- -- 16.0 16.0 20 20
6HK16500206 1.8 2.2 1 8.7 9.6 15.6 16.7 20 20
6HK16500506 3.6 4.4 1 17.3 19.1 26.4 28.7 30 30
6HK16500806 5.8 7.1 1 27.9 30.9 39.6 43.3 40 45
6HK16501006 7.2 8.8 1 34.6 38.3 48.0 52.6 50 60
6HK16501306 9.4 11.5 2 45.2 50.0 61.2 67.3 70 70
PCE4A30 10 57 15 1.3 3.8
none -- -- -- -- -- 17.4 17.4 25 25
6HK16500206 1.8 2.2 1 8.7 9.6 15.6 16.7 25 25
6HK16500506 3.6 4.4 1 17.3 19.1 26.4 28.7 30 30
6HK16500806 5.8 7.1 1 27.9 30.9 39.6 43.3 40 45
6HK16501006 7.2 8.8 1 34.6 38.3 48.0 52.6 50 60
6HK16501306 9.4 11.5 2 45.2 50.0 61.2 67.3 70 70
6HK16501506 10.8 13.2 2 51.9 57.4 69.7 76.5 70 80
PCE4A36 13 78 23 1.3 3.8
none -- -- -- -- -- 21.4 21.4 30 30
6HK16500206 1.8 2.2 1 8.7 9.6 15.6 16.7 30 30
6HK16500506 3.6 4.4 1 17.3 19.1 26.4 28.7 30 30
6HK16500806 5.8 7.1 1 27.9 30.9 39.6 43.3 40 45
6HK16501006 7.2 8.8 1 34.6 38.3 48.0 52.6 50 60
6HK16501306 9.4 11.5 2 45.2 50.0 61.2 67.3 70 70
6HK16501506 10.8 13.2 2 51.9 57.4 69.7 76.5 70 80
PCE4A42 18 112 28 1.3 5.4
none -- -- -- -- -- 29.1 29.1 45 45
6HK16500506 3.6 4.4 1 17.3 19.1 28.4 30.7 45 45
6HK16500806 5.8 7.1 1 27.9 30.9 41.6 45.3 45 50
6HK16501006 7.2 8.8 1 34.6 38.3 50.0 54.6 50 60
6HK16501306 9.4 11.5 2 45.2 50.0 63.2 69.3 70 70
6HK16501506 10.8 13.2 2 51.9 57.4 71.7 78.5 80 80
6HK16501806 13.0 15.9 2 62.5 69.1 84.9 93.2 90 100
6HK16502006 14.4 17.6 2 69.2 76.5 93.3 102.4 100 110
PCE4B48 22 117 34 1.7 5.4
none -- -- -- -- -- 34.4 34.4 50 50
6HK16500506 3.6 4.4 1 17.3 19.1 28.4 30.7 50 50
6HK16500806 5.8 7.1 1 27.9 30.9 41.6 45.3 50 50
6HK16501006 7.2 8.8 1 34.6 38.3 50.0 54.6 50 60
6HK16501306 9.4 11.5 2 45.2 50.0 63.2 69.3 70 70
6HK16501506 10.8 13.2 2 51.9 57.4 71.7 78.5 80 80
6HK16501806 13.0 15.9 2 62.5 69.1 84.9 93.2 90 100
6HK16502006 14.4 17.6 2 69.2 76.5 93.3 102.4 100 110
PCE4B60 24 144 38 1.7 7.0
none -- -- -- -- -- 39.2 39.2 60 60
6HK16500506 3.6 4.4 1 17.3 19.1 30.4 32.7 60 60
6HK16500806 5.8 7.1 1 27.9 30.9 43.6 47.3 60 60
6HK16501006 7.2 8.8 1 34.6 38.3 52.0 56.6 60 60
6HK16501306 9.4 11.5 2 45.2 50.0 65.2 71.3 70 80
6HK16501506 10.8 13.2 2 51.9 57.4 73.7 80.5 80 90
6HK16501806 13.0 15.9 2 62.5 69.1 86.9 95.2 90 100
6HK16502006 14.4 17.6 2 69.2 76.5 95.3 104.4 100 110
