York PCE4 Series User Manual

5126744-UIM-D-1015
Johnson Controls Unitary Products 9
Table 6: Electrical Data for 208-1-60 Multi Source Power
Model
Compressor
OD Fan
Motor
Blower
Motor
Electric Heat Option
Multi Source
Heater Kit
Heater kW
Stages
Heater Amps
RLA LRA MCC FLA FLA 208 208 208 208 208 208 208 208 208 208
Multi Source: Compressor
Circuit and Heat Circuits
Multi Source:
Circuit #1 Compressor Circuit
Circuit #2 Heat
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
MCA
1
Amps
MOP
2
Circuit #2 Heat
Circuit #3 Heat Circuit #1 Circuit #2 Circuit #3 Circuit #4
A24 9 45 14 1.3 3.8
none -- -- -- 16.0 20 -- -- -- -- -- --
6HK(0,1)6500206 1.8 1 8.7 16.0 20 10.8 15 -- -- -- --
6HK(0,1)6500506 3.6 1 17.3 16.0 20 21.6 25 -- -- -- --
6HK(0,1)6500806 5.8 1 27.9 16.0 20 34.9 40 -- -- -- --
6HK(0,1)6501006 7.2 1 34.6 16.0 20 43.3 45 -- -- -- --
6HK16501306 9.4 2 45.2 16.0 20 37.7 40 18.8 20 -- --
6HK26501306 9.4 1 45.2 16.0 20 56.5 60 -- -- -- --
A30 10 57 15 1.3 3.8
none -- -- -- 17.4 25 -- -- -- -- -- --
6HK(0,1)6500206 1.8 1 8.7 17.4 25 10.8 15 -- -- -- --
6HK(0,1)6500506 3.6 1 17.3 17.4 25 21.6 25 -- -- -- --
6HK(0,1)6500806 5.8 1 27.9 17.4 25 34.9 40 -- -- -- --
6HK(0,1)6501006 7.2 1 34.6 17.4 25 43.3 45 -- -- -- --
6HK16501306 9.4 2 45.2 17.4 25 37.7 40 18.8 20 -- --
6HK16501506 10.8 2 51.9 17.4 25 43.3 50 21.6 25 -- --
6HK26501306 9.4 1 45.2 17.4 25 56.5 60 -- -- -- --
6HK26501506 10.8 1 51.9 17.4 25 64.9 70 -- -- -- --
A36 13 78 23 1.3 3.8
none -- -- -- 21.4 30 -- -- -- -- -- --
6HK(0,1)6500206 1.8 1 8.7 21.4 30 10.8 15 -- -- -- --
6HK(0,1)6500506 3.6 1 17.3 21.4 30 21.6 25 -- -- -- --
6HK(0,1)6500806 5.8 1 27.9 21.4 30 34.9 40 -- -- -- --
6HK(0,1)6501006 7.2 1 34.6 21.4 30 43.3 45 -- -- -- --
6HK16501306 9.4 2 45.2 21.4 30 37.7 40 18.8 20 -- --
6HK16501506 10.8 2 51.9 21.4 30 43.3 50 21.6 25 -- --
6HK26501306 9.4 1 45.2 21.4 30 56.5 60 -- -- -- --
6HK26501506 10.8 2 51.9 21.4 30 64.9 70 -- -- -- --
A42 18 112 28 1.7 5.4
none -- 1 -- 29.5 45 -- -- -- -- -- --
6HK(0,1)6500506 3.6 1 17.3 29.5 45 21.6 25 -- -- -- --
6HK(0,1)6500806 5.8 1 27.9 29.5 45 34.9 40 -- -- -- --
6HK(0,1)6501006 7.2 1 34.6 29.5 45 43.3 45 -- -- -- --
6HK16501306 9.4 2 45.2 29.5 45 56.5 40 21.6 20 -- --
6HK16501506 10.8 2 51.9 29.5 45 43.3 50 21.6 25 -- --
6HK16501806 13.0 2 62.5 29.5 45 52.1 40 26.0 40 -- --
6HK16502006 14.4 2 69.2 29.5 45 43.3 45 43.3 45 -- --
6HK26501306 9.4 1 45.2 29.5 45 56.5 60 -- -- -- --
6HK26501506 10.8 1 51.9 29.5 45 64.9 70 -- -- -- --
6HK26501806 13.0 1 62.5 29.5 45 78.1 80 -- -- -- --
6HK26502006 14.4 1 69.2 29.5 45 86.5 90 -- -- -- --
B48 22 117 34 1.7 5.4
none -- -- -- 34.4 50 -- -- -- -- -- --
6HK(0,1)6500506 3.6 1 17.3 34.4 50 21.6 25 -- -- -- --
6HK(0,1)6500806 5.8 1 27.9 34.4 50 34.9 40 -- -- -- --
6HK(0,1)6501006 7.2 1 34.6 34.4 50 43.3 45 -- -- -- --
6HK16501306 9.4 2 45.2 34.4 50 56.5 40 21.6 20 -- --
6HK16501506 10.8 2 51.9 34.4 50 43.3 50 21.6 25 -- --
6HK16501806 13.0 2 62.5 34.4 50 52.1 40 26.0 40 -- --
6HK16502006 14.4 2 69.2 34.4 50 43.3 45 43.3 45 -- --
6HK26501306 9.4 1 45.2 34.4 50 56.5 60 -- -- -- --
6HK26501506 10.8 1 51.9 34.4 50 64.9 70 -- -- -- --
6HK26501806 13.0 1 62.5 34.4 50 78.1 80 -- -- -- --
6HK26502006 14.4 2 69.2 34.4 50 86.5 90 -- -- -- --
For notes, see Page 10.
