5126744-UIM-D-1015
Johnson Controls Unitary Products 15
1. Airflow tested with dry coil conditions, without air filters, at 230 volts
2. Applications above 0.8" w.c. external static pressure are not recommended.
3. Brushless DC high efficiency standard ECM blower motor used for all indoor blower assemblies.
4. Minimal variations in airflow performance data results from operating at 208 volts. Data above may be used in those cases.
5. Heating applications tested at 0.50" w.c. esp, and cooling applications tested at 0.30" w.c.esp per standards.
Table 10: Airflow - Bottom Duct Application
Model Motor Speed
External Static Pressure (Inches WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM
A24
Low (1) 899 869 827 782 734 685 630 575
Low/Medium (2) 1033 960 924 879 834 787 735 685
Medium (3) 1186 1133 1095 1056 1016 975 935 891
Medium/High (4) 1357 1322 1284 1248 1211 1174 1127 1087
High (5) 1480 1439 1404 1367 1369 1299 1264 1226
A30
Low (1) 1076 1042 1009 969 930 890 849 808
Low/Medium (2) 1104 1063 1025 987 947 908 869 830
Medium (3) 1205 1170 1136 1098 1060 1025 985 943
Medium/High (4) 1285 1251 1213 1179 1141 1104 1065 1027
High (5) 1406 1375 1341 1306 1271 1236 1198 1163
A36
Low (1) 1231 1186 1146 1103 1069 1030 977 912
Low/Medium (2) 1270 1225 1189 1140 1098 1046 1008 960
Medium (3) 1317 1286 1245 1198 1151 1110 1064 1024
Medium/High (4) 1358 1317 1275 1238 1197 1148 1105 1057
High (5) 1517 1475 1447 1400 1357 1318 1275 1232
A42
Low (1) 1455 1414 1379 1335 1294 1254 1212 1160
Low/Medium (2) 1566 1532 1492 1455 1416 1372 1333 1280
Medium (3) 1565 1530 1491 1458 1419 1381 1336 1290
Medium/High (4) 1675 1641 1606 1578 1535 1495 1455 1412
High (5) 1946 1909 1863 1815 1771 1721 1654 1595
B48
Low (1) 1598 1548 1502 1454 1410 1362 1307 1251
Low/Medium (2) 1663 1612 1568 1522 1476 1422 1370 1297
Medium (3) 1789 1733 1670 1650 1596 1578 1535 1483
Medium/High (4) 1931 1814 1808 1736 1673 1650 1597 1519
High (5) 2131 2058 1998 1949 1892 1840 1788 1728
B60
Low (1) 1655 1612 1596 1531 1461 1462 1429 1391
Low/Medium (2) 1766 1720 1667 1629 1632 1539 1537 1498
Medium (3) 1987 1933 1861 1817 1820 1715 1725 1651
Medium/High (4) 2114 2050 2047 1974 1899 1889 1920 1866
High (5) 2369 2308 2249 2183 2126 2088 2034 1990
Table 11: Electric Heat Minimum Supply Air
Model Voltage
Minimum Blower Speed for Electric Heat
Heater kW
258 1013151820 25
24 208/230-1-60 Low #1 Low #1 Med. Low #2 Med. #3 Med. Hi #4 -- -- -- --
30 208/230-1-60 Low #1 Low #1 Low #1 Med. Low #2 Med #3 High #5 -- -- --
36 208/230-1-60 Low #1 Low #1 Low #1 Low #1 Med. Low #2 High #5 -- -- --
42 208/230-1-60 -- Low #1 Low #1 Low #1 Low #1 Med. Low #2 Med. Hi #4 High #5 --
48 208/230-1-60 -- Low #1 Low #1 Low #1 Low #1 Low #1 Med. Low #2 Med. High #4 --
60 208/230-1-60 -- Low #1 Low #1 Low #1 Low #1 Low #1 Low #1 Med. Low #2 Med. High #4
Table 12: Electric Heat Multipliers
Voltage
kW Capacity Multipliers
1
1. Electric heaters are rated at nominal voltage. Use this table to determine
the electric heat capacity for heaters applied at lower voltages.
Nominal Applied
240
208 0.75
230 0.92
