FIGURE 42 - SAMPLE PRINTOUT (CUSTOM SCREEN REPORT)
YORK CUSTOM VIEW
CHILLER ID 0
(c) 1997 – 2001 YORK INTERNATIONAL CORPORATION
Mon 21 Jun 1999 1:28:25 PM
Leaving Chilled Liquid Temperature = 45.0°F
Return Chilled Liquid Temperature = 55.0°F
Leaving Condenser Liquid Temperature = 95.0°F
Return Condenser Liquid Temperature = 85.0°F
Evaporator Saturation Temperature = 41.0°F
Condenser Saturation Temperature = 78.5°F
Evaporator Pressure = 70.0 Psig
Condenser Pressure = 140.0 Psig
Oil Pressure = 45.0 Psid
% Full Load Amps = 50 %
FIGURE 41 - SAMPLE PRINTOUT (TREND DATA NEW OR EXISTING POINTS)
YORK TREND
CHILLER ID 163
© 1997 – 2000 YORK INTERNATIONAL CORPORATION
MON 09 OCT 2000 3:33:47 PM
DATA 1: LEAVING CHILLED LIQUID TEMPERATURE
DATA 2: RETURN CHILLED LIQUID TEMPERATURE
DATA 3: EVAPORATOR PRESSURE
DATA 4: LEAVING CONDENSER LIQUID TEMPERATURE
DATA 5: RETURN CONDENSER LIQUID TEMPERATURE
DATA 6: CONDENSER PRESSURE
TIME DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6
3:33:47PM 45.5°F 55.0°F 39.0 PSIG 95.0°F 85.0°F 120.0 PSIG
3:33:48PM 45.5°F 55.0°F 39.0 PSIG 95.0°F 85.0°F 120.0 PSIG
3:33:49PM 45.5°F 55.0°F 39.0 PSIG 95.0°F 85.0°F 120.0 PSIG
3:33:50PM 45.5°F 55.0°F 39.0 PSIG 95.0°F 85.3°F 120.1 PSIG
3:33:51PM 45.5°F 55.2°F 39.1 PSIG 95.1°F 85.4°F 120.2 PSIG
