Electromagnetic compatibility information Electromagnetic compatibility information
Guidance and manufacture s declaration-electromagnetic immunity'
Immunity test
IEC 60601 test level
Compliance level
3 Vrms
0,15 MHz-80 MHZ
6 V rms in ISM and amateur
radio bands between
0,15 MHz and 80 MHZ
80 % Am at 1 kHz
Conducted RF
IEC 61000-4-6
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations.
Electromagnetic propagation is affected by absorption and reflection from
structures, objects and people.
a
b
Radiated RF
IEC 61000-4-3
10 V/m
80 MHZ to 2.7 GHz
3 Vrms
0,15 MHz-80 MHZ
6 V rms in ISM and amateur
radio bands between
0,15 MHz and 80 MHZ
80 % Am at 1 kHz
The YE660F is intended for use in Electronic Blood Pressure Monitor
the or the electromagnetic environment specified below. The customer
user should assure of the YE660F Electronic Blood Pressure Monitor
that it is used in such an environment.
Table 3 For ME EQUIPMENT and ME SYSTEMS
that are not LIFE-SUPPORTING
10 V/m
80 MHZ to 2.7 GHz
Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio, AM and
FM radio broadcast and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the YE660F is used exceeds
the applicable RF compliance level above, the YE660F should be observed to
verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as reorienting or relocating the
.
YE660F.
Over the frequency range 150 kHz to 80 MHz, field strengths should be less
than 3 V/m.
Table 2 For all ME EQUIPMENT and ME SYSTEMS
Guidance and manufacture s declaration-electromagnetic emission'
Immunity test
IEC 60601 test level
Compliance level
Electrostatic
discharge (ESD)
IEC 61000-4-2
Electrical
fasttransient
/burst IEC
61000-4-4
±2 kV
100kHz repetition
frequency
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
±2 kV
100kHz repetition
frequency
Surge IEC
61000-4-5
±1 kV line(s)to line(s)
±2 kV line(s)to earth
±1 kV line(s)to line(s)
0% U ; 0.5 cycleT
o o o o o
At 0 , 45 , 90 , 135 , 180 , 225 ,
o o
270 and 315
o
Voltage dips
IEC 61000-4-11
NOTE: U is the a.c. mains voltage prior to application of the test level.
T
30A/m
50Hz or 60Hz
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
0% U ; 0.5 cycleT
o o o o o o
At 0 , 45 , 90 , 135 , 180 , 225 ,
o o
270 and 315
30A/m
50Hz or 60Hz
The YE660F Electronic Blood Pressure Monitor is intended for use
in the electromagnetic environment specified below. The customer
or the user of the YE660F Electronic Blood Pressure Monitor
should assure that it is used in such an environment.
0% U ; 1 cycle and 70% U ; T T
25/30 cycles
o
Single phase: at 0
0% U ; 250/300 cyclesT
Voltage
interruptions
IEC 61000-4-11
0% ; 1 cycle and 70% ; UT UT
25/30 cycles
o
Single phase: at 0
0% U ; 250/300 cyclesT
8A/m, CW for 30kHz
65A/m, 2,1kHz Pulse
modulation for 134,2kHz
7,5A/m, 50kHz Pulse
modulation for 13,56MHz
Proximity
magnetic fields
IEC 61000-4-39
8A/m, CW for 30kHz.
65A/m, 2,1kHz Pulse
modulation for 134,2kHz.
7,5A/m, 50kHz Pulse
modulation for 13,56MHz
