Zanussi ZITN643K User Manual

• Cookware made of cast iron, aluminium or
with a damaged bottom can cause
scratches on the glass / glass ceramic.
Always lift these objects up when you
have to move them on the cooking
surface.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
2.4 Care and cleaning
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Switch off the appliance and let it cool
down before cleaning.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to discard the
appliance correctly.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Before the installation
Before you install the hob, write down the
information below from the rating plate. The
rating plate is on the bottom of the hob.
Serial number ...........................
3.2 Built-in hobs
Only use the built-in hobs after you assemble
the hob into correct built-in units and work
surfaces that align to the standards.
3.3 Connection cable
• For a single phase or two phase
connection, use the cable type: H05BB-F
or H03V2V2-F which withstands a
temperature of 90 °C or higher.
• To replace the damaged mains cable, use
the cable: H05BB-F or H03V2V2-F which
withstands a temperature of 90 °C or
higher.
3.4 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
6 ENGLISH

Zanussi ZITN643K Specifications

General

Boost function	Yes
Large cooking zone	3700 W
Number of boosters	2
Simmer cooking zone	2500 W
Regular cooking zone	1800 W
Number of power levels	15
Timer type	Digital
Control type	Touch
Timer duration	99 min
Built-in display	-
Control position	Top right
Hob type	Zone induction hob
Product color	Black
Hob width size	59 cm
Top surface type	Ceramic
Appliance placement	Built-in
Cooking zone 2 type	Large
Cooking zone 3 type	Regular
Cooking zone 4 type	Simmer
Cooking zone 2 boost	3400 W
Cooking zone 2 power	2300 W
Cooking zone 4 power	1400 W
Cooking zone 1 position	Left rear
Cooking zone 2 position	Left front
Cooking zone 3 position	Right rear
Cooking zone 4 position	Right front
Number of cooking zones	4 zone(s)
Simmer cooking zone shape	Round
Cooking zone 3 power source	Electric
Large cooking zone diameter	210 mm
Number of gas cooking zones	0 zone(s)
Simmer cooking zone diameter	145 mm
Regular cooking zone diameter	180 mm
Connected load (gas)	- W

Weight and Dimensions

Depth	520 mm
Width	590 mm
Height	- mm
Installation compartment depth	490 mm
Installation compartment width	560 mm
Installation compartment height	44 mm
