10.4 Shortform table of the aux output #1 setting (traction version)
In traction configuration the AUX OUTPUT #1 setting specifies the handling of
the CNA#3 output and the STOP ON RAMP service (when the encoder is used).
This handling is summarized in the table below.
AUX
OUTPUT
#1
STOP ON
RAMP
A3 OUTPUT BEHAVIOUR ON A SLOPE
BRAKE ON -Drives the coil
of a
electromagnetic
brake.
The truck is electrically hold on a slope;
when the time set by "auxiliary time"
parameter is elapsed the brake is applied
and the 3-phase bridge is released. Do not
use this combination if the negative brake is
not installed.
BRAKE OFF -Drives the coil
of a
electromagnetic
brake.
The truck is not electrically hold on a slope,
but comes down very slowly; when the time
set by "auxiliary time" parameter is elapsed,
the brake is applied and the 3-phase bridge
is opened. Do not use this combination if
the negative brake is not installed.
HYDRO
CONT.
ON -Drives the coil
of a hydraulic
steering
contactor.
The truck is electrically hold on a slope;
when the time set by "auxiliary time"
parameter is elapsed, the truck comes down
very slowly, till the flat is reached.
HYDRO
CONT.
OFF -Drives the coil
of a hydraulic
steering
contactor.
The truck is not electrically hold on a slope,
but comes down very slowly till the flat is
reached.
EXCL.
HYDRO
ON -Drives the coil
of a hydraulic
steering
contactor.
The truck is electrically hold on a slope;
when the time set by "auxiliary time"
parameter is elapsed, the truck comes down
very slowly, till the flat is reached.
EXCL.
HYDRO
OFF -Drives the coil
of a hydraulic
steering
contactor.
The truck is not electrically hold on a slope,
but comes down very slowly till the flat is
reached.
