zarges PaxTower S-PLUS 1T User Manual

54
3.10 Scaffold towers and packages incl. ballasting
The parts list contains the designations, weight and order numbers of the individual
parts. It also provides the order numbers and contents of the various complete scaf-
fold towers.
The ballasting required for each scaffold tower is also listed.
Scaffold list and packages
Scaffold type Size 1 Size 2 Size 3 Size 4 Size 5 Size 6
Order no. 53521 53522* 53523 53524 53525 53526
Base package 53510 1 1 1 1 1 1
EN 1004 add-on package 53550 1 - - - - -
Stabiliser package 53551 - 1 1 1 1 1
Toeboard package 53552 - 1 1 1 1 1
One-metre extension package
S-PLUS 1T
53558 - 1 1 1 1 1
Two-metre extension package
S-PLUS 1T
53559 - - - 1 1 2
Two-metre push-on end frame 42782 - - 1 - 1 -
Ballast weights Number per castor; size 1: attached to the folding frame, sizes 2-6: attached to the stabiliser
Indoor use 42792 1 - - - - -
Outdoor use 42792 1 - - - 2 3
*) Scaffold tower 53522 contains one extra diagonal brace due to how the packages are put together.
Package list with individual components
Base package EN 1004 add-on package Stabiliser pack- age Toeboard pack- age One-metre extension pack- age S-PLUS 1T Two-metre extension pack- age S-PLUS 1T Two-metre push-on end frame
Order no. 53510 53550 53551 53552 53558 53559 42782
Folding frame unit with swivel
castors
42780 1 - - - - - -
One-metre push-on end frame 42781 - - - - 2 - -
Two-metre push-on end frame 42782 - - - - - 2 1
Advanced guardrail 42783 - - - - 2 2 -
Platform with trapdoor 42784 1 - - - - 1 -
End toeboard 42785 - 2 - 2 - - -
Side toeboard 42786 - 2 - 2 - - -
Diagonal brace 42787 - - - - 1 - -
Horizontal brace 42788 - 2 - - 1 - -
Triangular stabiliser 42789 - - 4 - - - -
