QLn Series User Guide
Figure 7: Ethernet Cradle (Four Bay for QLn220 & 320)
Docking Bay
Ethernet Status
Indicator
Figure 8: QLn-EC4 Dimensions
Power Status Indicator
Height Width Length
66,7 mm (2.62 in.) 579,9 mm (22.83 in.) 150,57 mm (5.93 in.)
Release Button
Note • The QLn220 and 320 extended battery capacity battery is not
compatible with the QLn-EC and EC4 Ethernet cradles.
