ZE500 Quick Reference Guide
Load Ribbon and Media
03/08/2012 P1047597-001
Remove Used Ribbon
Remove used ribbon from the ribbon take-up spindle each time you change the roll of ribbon.
To remove used ribbon, complete these steps:
1. Has the ribbon run out?
2. Slide the core with the used ribbon off of the ribbon take-up spindle.
3. Discard the used ribbon. You may reuse the empty core from the ribbon supply spindle by
moving it to the ribbon take-up spindle.
If the ribbon... Then
Ran out Continue with step 2.
Did not run out
a. Cut or break the ribbon before the ribbon take-up spindle.
b. Continue with step 2.
