9
ZE500 Quick Reference Guide
Load Ribbon and Media
03/08/2012 P1047597-001
5.
6.
Wind the ribbon around the core on the ribbon take-up spindle.
Caution • The printhead may be hot and could cause severe burns. Allow the
printhead to cool.
Thread the ribbon under the lower ribbon guide roller (1), under the printhead
assembly
(2), and then over the upper ribbon guide roller (3).
To Next Page
