Troubleshooting
Print Quality Problems
2/26/10 ZM400 User Guide for UPS P1016807-001 Rev. A
Vertical drift in
top-of-form position
The printer is out of calibration. Recalibrate the printer.
Vertical drift occurs during
normal printer operation.
Note • A vertical drift of
± 4 to 6 dot rows
(approximately 0.5 mm)
is within normal
tolerances.
Calibrate the printer.
The platen roller is dirty. Clean the platen roller. See Clean the Printhead
and Platen Roller on page 78.
Vertical image or
label drift
The printer is using
non-continuous labels but is
configured in continuous mode.
Configure the printer for non-continuous and run
calibration routine, if necessary.
The media sensor is positioned
incorrectly.
Ensure that the media sensor is properly
positioned to read a single/consistent interlabel
gap.
The media sensor is calibrated
improperly.
See Calibrate Media Sensor Sensitivity
on page 63.
The platen roller is dirty. Clean the platen roller. See Clean the Printhead
and Platen Roller on page 78.
Improper printhead pressure
settings (toggles).
Adjust the printhead pressure to ensure proper
functionality.
Improperly loaded media. Verify that the printer is loaded properly.
Incompatible media. Ensure that the interlabel gaps or notches are 2 to
4 mm and consistently placed. Media must not
exceed minimum specifications for mode of
operation.
The bar code printed
on a label does not
scan.
The bar code is not within
specifications because the print
is too light or too dark.
Perform the FEED Self Test on page 99. Adjust
the darkness or print speed settings as necessary.
Not enough blank space around
the bar code.
Leave at least 1/8 in. (3.2 mm) between the bar
code and other printed areas on the label and
between the bar code and the edge of the label.
Table 14 • Print Quality Problems (Continued)
Problem Possible Cause Recommended Solution
