Zebra ZT410 User Manual

Introduction
Printer Options
12
P1066582-003 ZT400 Series™ User Guide 8/25/15
Printer Options
The available printer options are shown in Figure 1. For information about the print modes that
can be used with the printer options, see Select a Print Mode on page 28.
Figure 1 • Printer Options
1
Tear-Off (standard)
2
Peel with Liner Take-Up option
3
Rewind option
4
Cutter option
12
34

Zebra ZT410 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Sustainability certificates	ENERGY STAR
Display	LCD
Color display	Yes
Product color	Black
Housing material	Metal
Ethernet LAN	-
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	512 MB
Certification	cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM, S-Mark (Arg), CCC, CU, BSMI, KCC, SABS, IN-Metro
Internal memory	256 MB
Built-in barcodes	1D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 49, Code 93, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, UPC-A, UPC-E
Ribbon width	110 mm
Ribbon length	450 m
Media thickness	0.058 - 0.25 mm
Maximum roll diameter	203 mm
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Package weight	18590 g

Weight and Dimensions

Depth	495 mm
Width	269 mm
Height	324 mm
Weight	16330 g
