Zell AC2000 - Technical Data; Spare Part List

31
11 Technical data
12 Spare part list
NO.
Parts Specification
1
Vacuum pump VE115
2
Vacuum pump oil 330mL
3
Filter drier 302
4
Service hose for high pressure side(red) 3m
5
Service hose for low pressure side(blue) 3m
6
Oil bottle 250mL
7
Hermetic compressor QD-10
8
High pressure gauge 80mm
9
Low pressure gauge 80mm
10
Tank pressure gauge 40mm
11
Service coupling for low pressure QC-ML
12
Service coupling for high pressure QC-MH
13
Solenoid valve Sv3
14
Liquid hose(red) 0.75m
15
Vapor hose (blue) 0.75m
Dimensions (width x height x depth)
600 mm x 1150 mm x 780 mm
Weight
95 kg
Power supply
220 V- 50 Hz
Refrigerant
R134a
Vacuum pump
120L / min
Compressor
3/8 P
Filling cylinder accumulator capacity
80 kg
LCD back-lit display
192*64
Manometers
80mm
Tank manometers
40mm
Scale resolution
5g
Service hose
3m
