* The EU version has 4 AC Outlets
**136W refers to the combined maximum output power of the Car Outlet and
the DC5521 ports together.
1. Specifications
General
Weight
Dimensions
Capacity
Wi-Fi
Cell Network & GPS
Outputs
AC (6*)
USB-C (4)
Car Charger (1)
DC5521 Output (3)
≈ 46.5lbs / 21.2kg
17.5 × 10.5 × 13.8in / 446 x 276 x 352mm
2,096Wh (44.8Ah/46.8V)
Supported
Supported
Pure Sine Wave, rated 2,000W (surge 4,000W),
100-120V~50/60Hz (US, JP version)
or 220-240V~50/60Hz (Other versions)
USB-C1/2: 5-20V, 100W Max Each
USB-C3/4: 5-12V, 20W Max Total
13.6V 10A, 136W** Max
13.6V 10A, 136W** Max Total
Inputs
AC Charge
Solar Charge
Car Charge
1,800W Max,
100-120V~50/60Hz (US, JP version)
or 220-240V~50/60Hz (Other versions)
12-60Vmp DC, 600W Max via XT60 input
60-160Vmp DC, 1,800W Max via AC input
Supports 12V/24V 10A Battery
Battery
Cell Chemistry
Warranty
Cycle Life
Li-NMC
2 years
3,000 cycles to 60%+ capacity
2
