p/n 4000087299 v.I
UTILIZATION:
This equipment is not to be disposed in normal waste, but be handled in accordance with
applicable waste disposal regulations in the country where the equipment is used.
1 SYSTEM DESCRIPTION
The Integrated Communication System Phontech 6200 is designed to meet the requirements for
internal communications and shore connections on board ships.
The system is based on the Phontech 6200 and the Phontech 6200R units. These units are 1U in
size, and may be combined into a complete scalable system effortlessly.
The Phontech 6200 units have a built in 2 port fast Ethernet switch for cascading. It supports ring
network for redundancy. One 1U unit supports up to 24 lines. FXS and FXO, 8 wire E&M and UpN
(61xx terminals) lines are supported. The units will support a mix of up to 6 line modules with 4
lines each. Each line is terminated in a RJ45 jack. A typical PABX configuration could be 5 x 4FXS +
1x4 FXO for a total of 20 telephones and 4 trunks. Typical intercom configuration could be
4x4UpN + 4FXO + 4E&M.
A 2x16 LCD character display with switches is provided to view status messages and configure
basic functions.
VoIP trunks and terminals are terminated using the Ethernet connection. Up to 50 VoIP (SIP)
registrations per unit are supported. A number of SIP trunk lines are supported on each of the
Phontech 6200 units.
The exchange cabinet is normally located on the ships bridge, or the electronic equipment room.
The intercom stations may be located in locations requiring two way communications, like the
engine room, engine control room, mooring stations, generator rooms etc.
The Phontech 6200 units have been tested and approved according to IEC 60945.
The Phontech 6200 units are backward compatible with Phontech 61xx terminal hardware.
Termination can be directly on the front panel using CAT5e type cable and RJ-45 connectors, or
using 19" patch panels and patch cables.
If using 6200R, a terminal board (4000019813) is required for easy termination. Less overall rack
space is used due to not requiring a 19” patch panel.
