3.2. MP
A 1601 PA CONTROL UNIT
-
Outer dimensions: 144 x 144mm.
- Operating voltage: 24VDC supplied from the MPA1600
Operation Unit.
- Current drain maximum: 300mA. (integrated in the MPA 1600)
- Microphone input level: 10mV typical (dynamic mic.)
- Ingress Protection (IP): 22
- Compass safe distance (standard): 80cm
- Compass safe distance (steering): 50cm
3.3. MPA 1604 PA CONTROL UNIT
-
Outer dimensions: 144 x 144mm.
- Operating voltage: 24VDC supplied from the MPA1600
Operation Unit.
- Current drain maximum: 300mA. (integrated in the MPA 1600)
- Microphone input level: 10mV typical (dynamic mic.)
- Ingress Protection (IP): 22
- Compass safe distance (standard)
1
: 80cm
- Compass safe distance (steering): 50cm
3.4. MPA 1603 GA ALARM PANEL
- Outer dimensions: 144 x 96mm.
- Operating voltage: 24VDC supplied from the MPA1600
Operation Unit.
- Current drain maximum: 100mA.
- Ingress Protection (IP): 22
- Compass safe distance (standard): 60cm
- Compass safe distance (steering): 40cm
3.5. MPA 1605 PA CONTROL UNIT
- Outer dimensions: 394 x 196 x 57,35 mm.
- Operating voltage: 24VDC supplied from the MPA1600
Operation Unit.
- Current drain maximum: 300mA. (integrated in the MPA 1600)
- Microphone input level: 10mV typical (dynamic mic.)
- Ingress Protection (IP): 22
- Compass safe distance (standard): 80cm
- Compass safe distance (steering): 50cm
1
(The uni
t is physically identical to MPA 1601)
