WRITE CONTROL LATCH (U30)
The control latch, U30, is written at the falling edge of
GLEN, which is the simultaneous assertion of pWR and the
YO output of the I/O address decoder. The pWR signal comes
directly from the GPU, and the YO signal occurs when AO,
A 1, and A2 are high, low, and high, respectively. The YO
and pWR signal s are ORed at U21-6 to form GLEN.
The organization of each bit in the control latch is as
follows:
BIT
SIGNAL NAME
FUNCTION
0.1 DSA.
DSB
00 = select drive
1
10
=
select drive 3
01 = select drive
2 11
=
select drive 4
2
8"/5"
0
=
sel ect 5.25"
1
=
select 8"
3
WEN
0
;;
deBt/hot. 1111
1
;;
/Seleot drive
drive.
.peoified by bit.
O.
1. and 2
4
PREC(}IP'
5.25" DDEN 0
=
precomp all
1
=
disable
precomp
tracks
8"
DDEN 0
=
precanp all
1
=
precomp
tracks
tracks
44-76
5 5" FASTEP 0
=
1797 operates
1
=
1797 operates
as specified
in 8" mode
by bit 2
6
WAITEN
0
=
wait state
1
=
wait state
enable
enable
7
SDEN
0
=
double density
1
=
single density
'(Note: Precomp is disabled in single density.)
When the WAITEN bit in the control latch is asserted, a
wait state is intitiated on the next read or write of the
data register. WAITEN couples through U23. U26, and U32
to the 3-100 ROY line. ROY goes low to put the GPU in a
wait state until the disk controller asserts ORQ at U22-38.
