Zenith HydroTap - CSHA 175 Model Installation Diagram

804050NZ- CS Commercial HydroTap - Installation Instructions - 09.2016 v3.01 Page 17 of 20
CH
336 mm
POWER
CORD
USBCHILLED
OUTLET
MAINS
IN
SPARKLING
OUTLET
CO2
IN
BLUE
WHITE
GAS IN
BRAIDED
Note:
- Mains hose
length is 750mm
- Plug and Cord
length is 1800mm
Position the under
sink unit close
to the outlet tap,
within reach of
the hose and cord
lengths supplied
Note:
Note:
All
All
silicon tubes
silicon tubes
must be cut to
must be cut to
size. They must
size. They must
have a constant
have a constant
fall back to the
fall back to the
unit.
unit.
4.6 Celsius Chilled Sparkling Model - CSHA 175
Installation Instructions
