General Maintenance
6.32
ABS Fuse
The ABS fuse is located on the frame under the RH front
body panel.
The ABS fuse holder (see arrow) is plugged into a
protective red cap. To release the fuse holder from the red
cap, gently pull the tab away from the cap and pull fuse
holder.
To replace the ABS fuse:
1. Remove the RH front body panel. See “
Removing the
RH front body panel”, on page 6-30.
2. Gently pull the tab (A) away from the red cap to release
the fuse holder and pull fuse holder.
3. Replace the fuse (0).
The ABS fuse value is listed below:
FUSE RATING CIRCUITS CONTROLLED
0 25A ABS-18 Motor
Zero Owner's Manual (FX and FXS).book Page 32 Monday, September 11, 2017 10:13 AM
