Troubleshooting
7.12
Understanding BMS Flash Code Patterns (Run Mode)
In this mode, the key is in the ON position.
1 RED 2 GREEN 3 GREEN 4 GREEN ON OFF MEANING SOLUTION
√ 5 sec 1 sec 25% of Power Remaining Charge Soon
√√ 5 sec 1 sec 50% of Power Remaining Charge Soon
√√√ 5 sec 1 sec 75% of Power Remaining Charge Soon
√√√√5 sec 1 sec 100% of Power Remaining OK
sec = seconds
ms = milliseconds
