Zero FX 2018 User Manual

General Operation
4.15
10.Subtract the second measurement (M2) from the first
measurement (M1).
Example:
The total sag is 1.97 in (50 mm). Refer to the chart below
for the correct sag. If the sag is not correct, the spring
preload should be adjusted.
MEASUREMENT OPERATOR VALUE
M1 24.02 in (610 mm)
M2 - 20.79 in (528 mm)
Sag = 3.22 in (82 mm)
MODEL SAG
FX & FXS 3.22 in (82 mm)
Zero Owner's Manual (FX and FXS).book Page 15 Monday, September 11, 2017 10:13 AM
