ZETRON 37-MAX - Connections to a Midland Basetech Repeater

Section 5. Installation
5-18
Connections to a Midland Basetech Repeater
For: Zetron Model 37-MAX
To: Midland Basetech Repeater
Using: 709-7179 Generic Radio Cable
37-MAX End
Function
J1
pin#
Wire
Color
Radio End
Connection/Notes
+12 volts DC 1 RED Pin-1, +12.6 V
Ground 2 BLACK Pin-8, Ground
Discriminator Input 3 WHITE Pin-3, RX Disc
Ground 4 BRAID No Connection
TX Audio Output 5 BLUE Pin-2, AF
Ground (spare) 6 N/C
PTT Output 7 ORANGE Pin-5, PTT
Ground 8 BROWN No connection
COR Input 9 YELLOW Pin-6, COS
CTCSS/DCS Encode 10 GREEN Pin-9, Tone
