ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
101
AND A, ir
Logical AND
Operation
A ← A AND ir
Description
The ir operand is any of the 8-bit registers IXH, IXL, IYH, or IYL. The ir operand is bit-
wise ANDed with the contents of the accumulator, A. The result is stored in the accumula-
tor.
Condition Bits Affected
Attributes
S Set if result is negative; reset otherwise.
Z Set if result is 0; reset otherwise.
H Set.
P/V Set if parity is even; reset otherwise.
N Reset.
C Reset.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
AND A,IXH X 2 DD, A4
AND A,IXL X 2 DD, A5
AND A,IYH X 2 FD, A4
AND A,IYL X 2 FD, A5
