Page #122 background image
eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
113
Condition Bits Affected
None.
Attributes
The opcode (kk) depends on the condition code being tested. According to the relevant
condition code, the opcode is assembled as indicated in Table 48.
1 .IS The starting Program Counter is PC[23:0]. Push the 2
LS bytes of the return address, PC[15:0], onto the
{MBASE, SPS} stack. Push the MS byte of the return
address, PC[23:16], onto the SPL stack. Push a 03h
byte onto the SPL stack, indicating a call from ADL
mode (because ADL = 1). Reset ADL mode bit to 0.
Load a 2-byte logical address {mm, nn} from the
instruction into PC[15:0]. The ending Program Counter
is {MBASE, PC[15:0]} = {MBASE, mm, nn}.
0 .IL The starting Program Counter is {MBASE, PC[15:0]}.
Push the 2-byte logical return address, PC[15:0], onto
the SPL stack. Push a 02h byte onto the SPL stack,
indicating a call from Z80 mode (because ADL = 0). Set
the ADL mode bit to 1. Load the 3-byte address {MM,
mm, nn} from the instruction into PC[23:0]. The ending
Program Counter is PC[23:0] = {MM, mm, nn}.
1 .IL The starting Program Counter is PC[23:0]} Push the 3-
byte return address, PC[23:0], onto the SPL stack. Push
a 03h byte onto the SPL stack, indicating a call from
ADL mode (because ADL = 1). The ADL mode bit
remains set to 1. Load a 3-byte address {MM, mm, nn}
from the instruction into PC[23:0]. The ending Program
Counter is PC[23:0] = {MM, mm, nn}.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
CALL cc,mn 03/6kk, nn, mm
CALL cc,Mmn 14/7kk, nn, mm, MM
CALL.IS cc,mn 04/740, kk, nn, mm
CALL.IS cc,mn 14/849, kk, nn, mm
CALL.IL cc,Mmn 05/852, kk, nn, mm, MM
CALL.IL cc,Mmn 15/95B, kk, nn, mm, MM
Table 47. Conditional Operations for CALL cc, Mmn Instruction (Continued)
