eZ80
®
CPU
User Manual
UM007714-0908
CPU Instruction Set
114
T
able 48. Opcode Assembly for CALL cc, Mmn Instructi
on (hex)
Condition
Relevant Flag
Opcode
NZ (non 0)
Z
C4
Z (0)
Z
CC
NC (no carry)
C
D4
C (carry)
C
DC
PO (parity od
d)
P/V
E4
PE (parity
even)
P/V
EC
P (sign positive)
S
F4
M (sign ne
gative/minu
s)
S
FC
