eZ80
®
CPU
User Manual
UM007714-0908
CPU Instruction Set
140
DI
Disable Interrupt
Operation
IEF1
←
0
IEF2
←
0
Description:
This instruction disables the maskable interru
pts by resetting the i
nterrupt enable flags
(IEF1 and IEF2).
Condition Bits Affected
None.
Attributes
Mnemonic
Operand
ADL Mode
Cycle
Opcode (hex)
DI
—X
1
F3
148
150
Table of Contents
Default Chapter
4
Table of Contents
4
Manual Objectives
6
About this Manual
6
Intended Audience
6
Manual Organization
6
Manual Conventions
7
Safeguards
9
Introduction
10
Architectural Overview
11
Processor Description
11
Pipeline Description
12
Memory Modes
15
Z80 MEMORY Mode
15
ADL MEMORY Mode
16
Registers and Bit Flags
18
Ez80 ® CPU Working Registers
18
Ez80 ® CPU Control Register Definitions
18
Ez80 ® CPU Control Bits
19
Ez80 CPU Registers in Z80 Mode
20
Ez80 CPU Registers in ADL Mode
21
Ez80 CPU Status Indicators (Flag Register)
23
Memory Mode Switching
27
ADL Mode and Z80 Mode
27
Memory Mode Compiler Directives
27
Opcode Suffixes for Memory Mode Control
27
Single-Instruction Memory Mode Changes
29
Suffix Completion by the Assembler
33
Assembly of the Opcode Suffixes
33
Persistent Memory Mode Changes in ADL and Z80 Modes
34
Mixed-Memory Mode Applications
43
MIXED MEMORY Mode Guidelines
43
Interrupts
45
Interrupt Enable Flags (IEF1 and IEF2)
45
Interrupts in Mixed Memory Mode Applications
45
Ez80 ® CPU Response to a Nonmaskable Interrupt
46
Ez80 CPU Response to a Maskable Interrupt
47
Vectored Interrupts for On-Chip Peripherals
52
Illegal Instruction Traps
55
I/O Space
56
Addressing Modes
57
CPU Instruction Set
61
Ez80 ® CPU Assembly Language Programming Introduction
61
Ez80 ® CPU Instruction Notations
62
Ez80 ® CPU Instruction Classes
63
Instruction Summary
68
Ez80 ® CPU Instruction Set Description
86
Opcode Maps
384
Glossary
391
Index
403
Customer Support
411
