eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
151
IN r, (BC)—also IN r, (C) for Z80 compatibility
Input from I/O
Operation
r ← ({UU, BC[15:0]})
Description
The CPU places the contents of the 16-bit BC multibyte register onto the lower two bytes
of the address bus at ADDR[15:0]. The upper byte of the address bus, ADDR[23:16] is
undefined for I/O addresses. The byte located at I/O address {UU, BC[15:0]} is written to
the specified register
r (A, B, C, D, E, H, or L).
Condition Bits Affected
Attributes
jj identifies the A, B, C, D, E, H, or L register and is assembled into one of the opcodes
indicated in Table 54.
S Set if byte is negative; reset otherwise.
Z Set if byte is 0; reset otherwise.
H Reset.
P/V Set if parity is even; reset otherwise.
N Reset.
C Not affected.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
IN r, (BC) X 3 ED, jj
