ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
150
IN A, (n)
Input from I/O
Operation
A ← ({UU, A, n})
Description
The n operand is placed on the lower byte of the address bus, ADDR[7:0]; the contents of
the accumulator, A, are placed on the middle byte of the address bus, ADDR[15:8]. The
upper byte of the address bus, ADDR[23:16] is undefined for I/O addresses. The byte at I/
O address {UU, A,
n } is written to the accumulator.
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
IN (n)X 3DB, nn
