ZiLOG eZ80 - Page 211

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
202
LD ir, ir’
Load
Operation
ir ← ir’
Description
The ir and ir’ operands are any of the 8-bit CPU registers IXH, IXL, IYH, or IYL. The
CPU writes the contents of the specified register
ir’ to the selected register ir .
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LD IXH,IXH X 2 DD, 64
LD IXH,IXL X 2 DD, 65
LD IXL,IXH X 2 DD, 6C
LD IXL,IXL X 2 DD, 6D
LD IYH,IYH X 2 FD, 64
LD IYH,IYL X 2 FD, 65
LD IYL,IYH X 2 FD, 6C
LD IYL,IYL X 2 FD, 6D
