UM007714-0908 CPU Instruction Set
228
LD rr, (HL)
Load Register
Operation
rr ← (HL)
Description
The rr operand is any of the multibyte CPU registers BC, DE, or HL. The CPU writes the
contents of the memory location specified by the HL register to the multibyte
rr register.
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LD BC,(HL) 0/1 4/5 ED, 07
LD.S BC,(HL) 1 5 52, ED, 07
LD.L BC,(HL) 0 6 49, ED, 07
LD DE,(HL) 0/1 4/5 ED, 17
LD.S DE,(HL) 1 5 52, ED, 17
LD.L DE,(HL) 0 6 49, ED, 17
LD HL,(HL) 0/1 4/5 ED, 27
LD.S HL,(HL) 1 5 52, ED, 27
LD.L HL,(HL) 0 6 49, ED, 27
