eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
227
LD r, r’
Load Register
Operation
r ← r’
Description
The
r
and
r’
operands are any of A, B, C, D, E, H, or L. The CPU writes the contents of
the
r’
register to the
r
register. The
r’
register described here should not be confused with
the registers in the alternate working register set.
Condition Bits Affected
None.
Attributes
jj = binary code 01 ddd sss where ddd identifies the destination A, B, C, D, E, H, or L
register and
sss identifies the source A, B, C, D, E, H, or L register assembled in the
object code, as indicated in Table 70.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LD r,r’ X1jj
Table 70. Register and jj Opcodes for LD r, r’ Instruction (hex)
Register jj (ddd or sss)
A 111
B 000
C 001
D 010
E 011
H 100
L 101
