ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
243
LEA IX/Y, IY+d
Load Effective Address
Operation
IX/Y ← IY+d
Description
The CPU adds the contents of the IY register to the two’s-complement displacement d and
writes the sum to the specified multibyte Index Register, IX or IY.
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LEA IX,IY+d X3ED, 54, dd
LEA.S IX,IY+d 1452, ED, 54, dd
LEA.L IX,IY+d 0449, ED, 54, dd
LEA IY,IY+d X3ED, 33, dd
LEA.S IY,IY+d 1452, ED, 33, dd
LEA.L IY,IY+d 0449, ED, 33, dd
