ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
258
OTDM
Output to I/O and Decrement
Operation
({UU, 00h,C}) ← (HL)
B ← B – 1
C ← C – 1
HL ← HL – 1
Description
The CPU loads the contents of the memory location specified by the multibyte HL register
into CPU memory. The CPU next outputs this byte to the I/O address specified by the C
register with the High byte of the address, ADDR[15:8], forced to 0. The upper byte of the
address bus, ADDR[23:16] is undefined for I/O addresses. The B, C, and HL registers are
decremented.
Condition Bits Affected
Attributes
S Undefined.
Z Set if B – 1 = 0; reset otherwise.
H Undefined.
P/V Undefined.
N Set if msb of data is logical 1; reset otherwise.
C Undefined.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
OTDM —X 5ED, 8B
OTDM.S —1 652, ED, 8B
OTDM.L —0 649, ED, 8B
