ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
264
OTIM
Output to I/O and Increment
Operation
({UU, 00h,C}) ← (HL)
B ← B – 1
C ← C+1
HL ← HL+1
Description
The CPU loads the contents of the memory location specified by the multibyte HL register
into CPU memory. The CPU next outputs this byte to the I/O address specified by the C
register with the High byte of the address, ADDR[15:8], forced to 0. The upper byte of the
address bus, ADDR[23:16] is undefined for I/O addresses. The B register decrements. The
C and HL registers increment.
Condition Bits Affected
Attributes
S Undefined.
Z Set if B – 1 = 0; reset otherwise.
H Undefined.
P/V Undefined.
N Set if msb of data is logical 1; reset otherwise.
C Undefined.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
OTIM —X 5ED, 83
OTIM.S —1 652, ED, 83
OTIM.L —0 649, ED, 83
