PEA IX+d
Push Effective Address
Operation
if ADL mode{
(SPL – 1) ← IXd[23:16]
(SPL – 2) ← IXd[15:8]
(SPL – 3) ← IXd[7:0]
SPL ← SPL – 3
}
else Z80 mode {
(SPS – 1) ← IXd[15:8]
(SPS – 2) ← IXd[7:0]
SPS ← SPS – 2
}
where IXd indicates the sum of the contents of the register IX and the two’s-complement
displacement d .
Description
In ADL mode, the 24-bit sum of the contents of IX and the two’s-complement displace-
ment
d is pushed onto the stack at SPL. The stack pointer, SPL, decrements by 3.
In Z80 mode, the 16-bit sum of the contents of IX and the two’s-complement displacement
d is pushed onto the stack at SPS. The stack pointer, SPS, decrements by 2.
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
PEA IX+d 0/1 5/6 ED, 65, dd
PEA.S IX+d 1652, ED, 65, dd
PEA.L IX+d 0749, ED, 65, dd
