ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 Memory Mode Switching
31
RET.S 1 — An invalid suffix. RET.L must be used in all mixed-
memory mode applications.
RET.L 0 RET.LIS
assembles to
49 C9
The starting program counter is {MBASE,
PC[15:0]}. Pop a byte from SPL into ADL to set
memory mode (03h = A D L , 02h = Z 8 0 ) .
if ADL mode {
Pop the upper byte of the return address from SPL
into PC[23:16].
Pop 2 LS bytes of the return address from {MBASE,
SPS} into PC[15:0].
The ending program counter is PC[23:0].
}
else Z80 mode {
Pop a 2-byte return address from {MBASE,SPS}
into PC[15:0].
The ending program counter is {MBASE,
PC[15:0]}.
}
RET.L 1 RET.LIL
assembles to
5B C9
The starting program counter is PC[23:0]. Pop a
byte from SPL into ADL to set memory mode
(03h = ADL, 02h = Z80).
if ADL mode {
Pop 3-byte return address from SPL into PC[23:0].
The ending program counter is PC[23:0].
}
else Z80 mode {
Pop a 2-byte return address from SPL into PC[15:0].
The ending program counter is {MBASE,
PC[15:0]}.
}
Table 19. RETI Instruction
User Code
ADL
Mode
Assembled
Code Operation
RETI 0 RETI
assembles to
ED 4D
The starting program counter is {MBASE,
PC[15:0]}. Pop a 2-byte return address from
{MBASE, SPS} into PC[15:0]. The ADL mode bit
remains cleared to 0. The ending program counter
is {MBASE, PC[15:0]}.
Table 18. RET Instruction (Continued)
User Code
ADL
Mode
Assembled
Code Operation
