UM007714-0908 Interrupts
42
Table 24. Interrupt Mode 2 Operation
Memory Mode
ADL
Bit
MADL
Bit Operation
Z80 Mode 0 0
Read the LSB of the interrupt vector placed on the data bus,
D[7:0], by the interrupting peripheral.
• IEF1 ← 0
• IEF2 ← 0
• The starting Program Counter is effectively {MBASE,
PC[15:0]}.
• Push the 2-byte return address PC[15:0] onto the
({MBASE,SPS}) stack.
• The ADL mode bit remains cleared to 0.
• The interrupt vector address is located at { MBASE,
I[7:0], D[7:0] }.
• PC[15:0] ← ( { MBASE, I[7:0], D[7:0] } ) .
• The ending Program Counter is effectively {MBASE,
PC[15:0]}
• The interrupt service routine must end with RETI.
ADL Mode 1 0
Read the LSB of the interrupt vector placed on the data bus,
D[7:0], by the interrupting peripheral.
• IEF1 ← 0
• IEF2 ← 0
• The starting Program Counter is PC[23:0].
• Push the 3-byte return address, PC[23:0], onto the SPL
stack.
• The ADL mode bit remains set to 1.
• The interrupt vector address is located at { I[15:0], D[7:0]
}.
• PC[23:0] ← ( {I[15:0], D[7:0] } ) .
• The ending Program Counter is { PC[23:0] }.
• The interrupt service routine must end with RETI.

ZiLOG eZ80 Specifications

General

CPU Family	eZ80
Core	eZ80
Architecture	8-bit
Clock Speed	up to 50 MHz
Addressable Memory	16 MB
Register Size	8-bit
Serial Interfaces	UART, SPI, I2C
Operating Temperature	-40°C to +85°C
Instruction Set	Z80 compatible
On-Chip Flash Memory	Up to 256 KB
On-Chip SRAM	Up to 16 KB
Operating Voltage	3.0V to 3.6V
Package Types	LQFP, QFP
Timers	Multiple timers/counters
Power Consumption	Low power

Summary

Introduction

Architectural Overview

Processor Description

Pipeline Description

Memory Modes

Z80 MEMORY Mode

Describes Z80-compatible addressing with 16-bit registers and default operating mode on reset.

ADL MEMORY Mode

Explains ADL mode utilizing 16MB linear addressing and 24-bit registers.

Registers and Bit Flags

eZ80® CPU Working Registers

Details the two banks of working registers: main and alternate.

eZ80® CPU Control Register Definitions

Lists registers controlling CPU operation: I, IX, IY, MBASE.

eZ80® CPU Control Bits

eZ80® CPU Registers in Z80 Mode

Details CPU registers and bit flags when operating in Z80 mode.

Memory Mode Switching

ADL Mode and Z80 Mode

Opcode Suffixes for Memory Mode Control

Mixed-Memory Mode Applications

MIXED MEMORY Mode Guidelines

Interrupts

Interrupt Enable Flags (IEF1 and IEF2)

Interrupts in Mixed Memory Mode Applications

eZ80® CPU Response to a Nonmaskable Interrupt

Details how the CPU accepts and responds to nonmaskable interrupts (NMIs).

eZ80® CPU Response to a Maskable Interrupt

Describes how the CPU responds to maskable interrupts using Interrupt Modes 0, 1, and 2.

I/O Space

Addressing Modes

Register Indirect Addressing

CPU Instruction Set

eZ80® CPU Assembly Language Programming Introduction

eZ80® CPU Instruction Notations
